mov 32d electrical characteristic
|
part number
|
maximum allowable voltage |
varistor voltage |
maximum clamping voltage |
withstanding surge voltage |
maximum energy current |
typical capacitance (reference) |
||
|
vac(v) |
vdc(v) |
v1ma(v) |
ip(a) |
vc(v) |
i(a) |
(j) |
@1khz(pf) |
|
|
330kd32 |
20 |
26 |
33(29.5~36.5) |
40 |
65 |
8000 |
40 |
30000 |
|
390kd32 |
25 |
31 |
39(35~43) |
40 |
77 |
8000 |
50 |
22000 |
|
470kd32 |
30 |
38 |
47(42~52) |
40 |
93 |
8000 |
60 |
19000 |
|
560kd32 |
35 |
45 |
56(50~62) |
40 |
110 |
8000 |
70 |
16700 |
|
680kd32 |
40 |
56 |
68(61~75) |
40 |
135 |
8000 |
85 |
15000 |
|
820kd32 |
50 |
65 |
82(74~90) |
200 |
136 |
20000 |
100 |
12800 |
|
101kd32 |
60 |
85 |
100(90~110) |
200 |
165 |
20000 |
125 |
10500 |
|
121kd32 |
75 |
100 |
120(108~132) |
200 |
200 |
20000 |
150 |
8700 |
|
151kd32 |
95 |
125 |
150(135~165) |
200 |
250 |
20000 |
190 |
7000 |
|
181kd32 |
115 |
150 |
180(162~198) |
200 |
300 |
20000 |
225 |
5800 |
|
201kd32 |
130 |
170 |
200(180~220) |
200 |
340 |
25000 |
250 |
5200 |
|
221kd32 |
140 |
180 |
220(198~242) |
200 |
360 |
25000 |
270 |
5150 |
|
241kd32 |
150 |
200 |
240(216~264) |
200 |
395 |
25000 |
290 |
5100 |
|
271kd32 |
175 |
225 |
270(243~297) |
200 |
455 |
25000 |
300 |
4800 |
|
301kd32 |
190 |
250 |
300(270~330) |
200 |
500 |
25000 |
330 |
4550 |
|
331kd32 |
210 |
275 |
330(297~363) |
200 |
550 |
25000 |
360 |
4300 |
|
361kd32 |
230 |
300 |
360(324~396) |
200 |
595 |
25000 |
380 |
3900 |
|
391kd32 |
250 |
320 |
390(351~429) |
200 |
650 |
25000 |
400 |
3200 |
|
431kd32 |
275 |
350 |
430(387~473) |
200 |
710 |
25000 |
430 |
3100 |
|
471kd32 |
300 |
385 |
470(423~517) |
200 |
775 |
25000 |
460 |
2800 |
|
511kd32 |
320 |
415 |
510(459~561) |
200 |
845 |
25000 |
510 |
2700 |
|
561kd32 |
350 |
460 |
560(504~616) |
200 |
925 |
25000 |
540 |
2550 |
|
621kd32 |
385 |
505 |
620(558~682) |
200 |
1025 |
25000 |
570 |
2400 |
|
681kd32 |
420 |
560 |
680(612~748) |
200 |
1120 |
25000 |
600 |
2200 |
|
751kd32 |
460 |
615 |
750(675~825) |
200 |
1240 |
25000 |
620 |
2000 |
|
781kd32 |
485 |
640 |
780(702~858) |
200 |
1290 |
25000 |
660 |
1900 |
|
821kd32 |
510 |
670 |
820(738~902) |
200 |
1355 |
25000 |
700 |
1800 |
|
911kd32 |
550 |
745 |
910(819~1001) |
200 |
1500 |
25000 |
750 |
1300 |
|
951kd32 |
550 |
745 |
910(819~1001) |
200 |
1500 |
25000 |
780 |
1200 |
|
102kd32 |
625 |
825 |
1000(900~1100) |
200 |
1650 |
25000 |
810 |
1100 |
|
112kd32 |
680 |
895 |
1100(990~1210) |
200 |
1815 |
25000 |
910 |
1000 |
|
122kd32 |
750 |
990 |
1200(1080~1320) |
200 |
1980 |
25000 |
960 |
920 |
|
142kd32 |
880 |
1140 |
1400(1260~1540) |
200 |
2310 |
25000 |
1020 |
800 |
|
162kd32 |
1000 |
1280 |
1600(1440~1760) |
200 |
2640 |
25000 |
1080 |
700 |
• the tolerance of varistor voltage between 18v and 27v is more than 10%.
• varistor voltage≥1200v, structure diagram is f type.
 |
 |
